In the rapidly evolving landscape of biotechnology, the field of cell culture has witnessed remarkable
Product Description
Suitable for culture of microbes with low shear force
lnternal or external light sources with adjustable intensity can be provided. The culture of marine organisms, especially the cells and tissues of microalgae and macroalgae, is a research focus all overthe world. Among them, some secondary metabolites such as marine terpenoids are widely studied secondary metabolites.Bailun has nearly 20 years of research experience in the lighting culture and photoreaction field.The lighting bioreactor is aresult of these research experiences.
The lighting bioreactor in the BLBlO-GCL series is suitable for culture of algae cells and tissues. It adopts a long and narrowtank with a total volume of 3.6L and tank cover specification of 115NW. lt is provided with specially designed low positioncooling jacket and outer casing type light source to ensure the transmission effect of lighting. It has various types of mixingpaddles for selection such as flat paddle, bevel paddle and turbine paddle,The light intensity can be adjusted freelyaccording to the percentage.When working with the BLBlO-/3.1 software, it can simulate various lighting modes, such asday and night alternation.
Control system: 10in touch screen , Siemens PLC control system with control parameters (stirring, pH, DO, temperature, feeding, gas etc.),
data analysis, data logging, data output and printing, overrun alarm, language switching and other functions
parallel bioreactor
| Total volume | 0.2L~40L | ||
| Working volume | 50%~70% | ||
| Stirring system | Magnetic drive or Mechanical drive, 2 height a djustable
six – blade stirrer |
||
| Sterilization | Off-site sterilization(Autoclave) | ||
| Gas control | Manual control by rotor meter (standard)
Auto control by mass flow meter( optional) |
||
| Feeding | 4 fixed peristaltic pump( standard)
Variable speed peristaltic pump(optional) |
||
| Illumination system | LED light (white, blue, green, red) with adjustable intensity
available (intensity 0 until 50micromol-m. seg2) and photoperiod |
||
| Basic sensor | Stanaded with pH, DO, Temperature, Foam
Optional: Liquid Level sensor, OD sensor, Turbidity sensor, ORP sensor, Weight system, Live cell sensor etc. |
||
Parameter Description Total volume 10L,15L,20L,30L,50L,70L,100L,200L,300L,500Letc. Working volume 30%~70% Tank Jacket tank, made by SS316 and SS304, tank design pressure 0.3Mpa,…
Features Cell contact materials are safe and non-toxic to ensure cell vitality and product safety. 304 stainless steel shell, no…
Airlift Bioreactor Vessels biological fermentation Volume: 200L – 700L, with 70-85% working volume Material: Tank SUS316L, jacket SUS304 (polishing better…
Parameter Description Total volume 5L,10L,15L,20L,30L,50L,100L,200L,500L,1000L, 5KL, 50KL, 500KL etc. Working volume 30%~70% Tank Jacket tank, made by SS316 and SS304,…
Parameter Description Total volume 5L,10L,15L,20L,30L,50L,100L,200L,500L,1000L, 5KL, 50KL, 500KL etc. Working volume 30%~70% Tank Jacket tank, made by SS316 and SS304,…
