International Technology in Cell Culture Bioreactor
June 5, 2025
In the rapidly evolving landscape of biotechnology, the field of cell culture has witnessed remarkable
| Brand | BAILUN bio Bioreactor and Fermenter Manufacturer |
| Model | BLBIO-GJAV |
| Weight | 300 KG |
| Warranty | 1 Year |
| Machinery Capacity | 5L – 200KL |
| Machinery Test Report | Provided |
| Warranty of Core Components | 1 Year |
| Core Components | Gearbox, Motor, Gear, Pump, Pressure Vessel, PLC |
| Key Selling Points | Automatic |
| Marketing Type | New Product 2024 |
| Video Outgoing Inspection | Provided |
| Processing | Fermenting Equipment |
| Terms of Payment | L/C, D/A, D/P, Western Union |
|
Parameter
|
Description
|
||
|
Total volume
|
10L,15L,20L,30L,50L,70L,100L,200L,300L,500Letc.
|
||
|
Working volume
|
30%~70%
|
||
|
Tank
|
Diameter: Hight ratio 1:2to3, Tank made by SUS316L stainless steel.
Jacket is SUS304 stainless steel.
|
||
|
Stirring system
|
Mechanical sealing system : high-powered stirring oar, anti-foam oar; AC electrical machine: infinite speed variation; rpm in the fermenter: 50~1000 rpm±1%,The height of the stirring oar can be adjusted
|
||
|
Sterilization
|
Sterilize in place(SIP), auto control by program
|
||
|
Clean
|
Clean in place (CIP) by spray ball
|
||
|
Gas control
|
Control by rotor meter, air flow 1 vvm
|
||
|
Feeding
|
Automatically feeding by peristaltic pump
|
||
|
Anti-foam control
|
Automatically add antifoam by peristaltic pump
|
||
|
Temperature control
|
Heat by thermostatic water tank and circulate by circulating pump(Grundfos, Denmark), auto control (cooling water+5℃) to 65℃±0.1℃,temperature probe(PT100)
|
||
|
PH control
|
2.00-12.00±0.05pH, autocontrol by adding acid and base, pH sensor (Mettler, Switzerland) and shielding lead (Mettler, Switzerland). fermenter is autocontrolled with peristaltic pump
|
||
|
Do control
|
0-150±3% displaying precision 0.1%, sensor (Mettler/Hamilton, Switzerland) and shielding lead(Mettler/Hamilton, Switzerland)
|
||
|
Sampling
|
Sampling valve, can sterilization separately, manual
|
||
|
Harvest
|
Zero dead zone bottom valve(Gemu/Burket,Germany), can sterilization separately, manual/auto
|
||
|
Lid lift system
|
30L-500L have lid lift system, 700-1000L have human hole.
|
||
|
Innoculation
|
4 valves group or pin in with flam protection
|
||
|
Pressure
|
Auto control, BD Germany pressure transmitter or Lambert differential pressure liquid level gauge.
|
||
|
Exhaust
|
Have condenser before exhaust, control by diagram valve / Proportional control valve.
|
||
|
Control parameters
|
10in touch screen, Siemens PLC control system with control parameters (stirring, pH, DO, temperature, feeding, gas etc.), data analysis, data logging, data output and printing, overrun alarm, language switching and other functions
|
||
|
Optional configuration
|
O2/N2/CO2 gas control, Level sensor, OD sensor, Turbidity sensor, ORP sensor, Weight system, Live cell sensor etc.
|
||
