| Brand | BAILUN bio Bioreactor and Fermenter Manufacturer |
| Model | BLBIO-SS |
| Brand Name | Bailun |
| Voltage | 220/380 Volt 50/60 Hz |
| Power | 0.75KW – 75KW |
| Terms of Payment | Western Union, T/T |
The solid fermenter system is used in such industries as medicine, beverage, enzymic preparations,biological pesticide,etc. It is a kind of fermenter equipment with volumes of 5L-20KL with suchadvantages as saved investment,good aseptic performance, saved operation environment,simplemaintenance,no easy pollution to the environment, etc.
microbial fermenters
SlP and cooling: Steam is directly connected to the fermenter, and the purpose of high temperature SIP is realized after itworks with the special mixing system.
Temperature and humidity control:The temperature is digitally displayed. Air volume is adopted to control the temperature.The material temperature is controlled by adopting the full atomizing water supply system.
ln-place seeding and mixing: ln-place differential pressure even seeding. During fermentation, the material mixing andcrushing system in the tank ensures even and stable fermentation.
Horizontal solid fermenter: Convenient observation of materials, thorough discharging.
Control parameters: temperature, rotation speed, humidity.
| Total volume | 5L~1000L | ||
| Working volume | 30%~50% | ||
| Material | 316L stainless steel inside and 304 jacket | ||
| Stirring system | Rotating shaft | ||
| Sterilization | On-site sterilization manual control | ||
| Gas control | Manual control by rotor meter | ||
| Temperature control | Electric heating, water cooling, circulation pump temperature control | ||
| Feeding | 4 fixed peristaltic pump( standard)
Variable speed peristaltic pump(optional) |
||
| Basic sensor | Stanaded with Temperature,Humidity | ||
