Stainless Steel For Microorganism Cultivation hyperforma bioreactor

Stainless Steel For Microorganism Cultivation hyperforma bioreactor
Stainless Steel For Microorganism Cultivation hyperforma bioreactor - Image 2
Stainless Steel For Microorganism Cultivation hyperforma bioreactor - Image 3
Categories
Mammalian cell bioreactor(5L-10KL)

Additional information

Brand BAILUN bio Bioreactor and Fermenter Manufacturer
Model BL01
Type Fermentation Extraction
Marketing Type New Product 2024
Warranty of Core Components 1 Year
Download
PDF
PDF
PDF
PDF
PDF
Update Time
June 4, 2025

Detail Information

Features:

Parameter Description for mammallian cell fermenter glass fermenter lab fermenter

Total volume: 0.2L,0.5L,1L,2L,3L,5L,10L,20L,30L,40L etc.
Working volume: 50%~70%
Tank: Single glass vessel with stainless steel bottom. Lid made by stainless steel 316L with ports, condenser on the cover
Stirring system Mechanical drive(GJ type) or Magnetic drive(GC type, bottom/top drive), 3 six-blade paddle and 1 foam breaker, each paddle height adjustable.
Stir speed: 50~1000rpm/50-500rpm
Sterilization： Off-site sterilization (Autoclave)
Gas control： Control by rotor meter or mass flow meter (MFC) , air flow 1-2vvm, O2 flow:0.1-0.2vvm Co2 flow:0.1-0.2vvm .N2 flow:0.1-0.2vvm
Feeding： Automatically feeding by peristaltic pump
Anti-foam control： Automatically add antifoamer by peristaltic pump
Temperature control： Auto-control, electric heating range water source add 5ºC to 70ºC
PH control： PH 2.00-12.00±0.1, auto-control adding acid/base by peristaltic pump, pH sensor from Hamilton/Mettler, Switzerland.
DO control： 0-150±3% displaying precision 0.1%, DO sensor from Hamilton/Mettler, Switzerland. DO coupling with agitation, oxygen.
Sampling： Manual sampling
Control parameters： 10 or 15 inch touch screen , Siemens PLC with control parameters (stirring, pH, DO, temperature, feeding, alarm, gas etc.), data analysis, data record, data output, language(RU/EN/CN) and other customized functions
Optional configuration： Remote control, Mass flow meter(auto control gas), O2/N2/CO2, gas(CO2) exhaust analysis, Level sensor, Turbidity(OD) sensor, ORP sensor, weight system, Live cell sensor(Biomass), Printing, Siemens touch screen, etc.,
hyperforma bioreactor type:

Machine: infinite speed variation; rpm: 70~1200rpm±1%,the height of the stirring oar can be adjusted
Magnetic Drive from bottom, without mechanical seal
Our product range:
1, Glass fermenter from mini 0.2L to 40L,
2, Stainless steel fermenter for reasearch-pilot-industry like 2L-500L-5000L-500KL.
3, Relative device: Steam generator, Chiller, Air compressor, Tubular centrifuge, Disc centrifuge, Shaker,etc.

Fermenter/bioreactor application:

1, Animal vaccine production: Avian influenza vaccine, Porcine PRRS vaccine, Foot-and-mouth disease, Rabies vaccine, Mink vaccine, DTP vaccine, Diphtheria vaccine, Tetanus vaccine, etc.
2, Human vaccine production: Diphtheria vaccine, Diphtheria vaccine, Tetanus vaccine, Meningitis vaccine, Pneumonia IV vaccine, Hepatitis B vaccine, Coronavirus disease-19 vaccine, etc.
3, Culture for microorganism (bacterial,fungi,yeast.etc), mammalian cell(293,CHO etc.), plant cell, algae, enzyme, protein, additives, antibiotics etc.

Our Factory:

We have three bioreactor fermenter factories in China, one located in Shanghai, two located in Lianyungang city. Welcome to visiting.
